Clema prindere SAUTER AE 500

1.160,25 RON
  • Rapid adaptation to the most varied test objects
  • Solid version
  • Flexible range from 0-10 mm

Categorie de produse: Masurare forta

Material Carcasa: aluminium

Dimensiuni carcasa (fara piese detasabile): 51×41×15 mm

Greutate neta: 0,10 kg

SPECIFICATII TEHNICE: Fisa Tehnica

BROSURA PRODUS: Brosura Produs

In stoc

Durata de livrare: Consulta pagina informatii livrare!

Limita stoc
Adauga in cos
Cod Produs: AE 500 Ai nevoie de ajutor? +40772074478
Adauga la Favorite Cere informatii
1.160,25 RON * *plus costuri de livrare, TVA inclus
In stoc

Durata de livrare: Consulta pagina informatii livrare!

Limita stoc
Adauga in cos

Standard:

Descriere

  • High-quality screw tension clamp in the lower force range with an enormous flexibility for a fast adaptation to a wide variety of test objects
  • Solid version for high clamp forces
  • Flexible clamping width (width between the jaws) from 0-10 mm
  • Jaws with pyramid grip as standard, W×H 15×10 mm
  • The modular construction enables a quick adaptation and cleaning of the clamp
  • The threaded rods with hexagon socket allow the test objects to be securely clamped with standard tools and thus adapted to the user's own requirements and operating conditions, e.g. use with a test stand or measuring device, etc.
  • Can be used with all SAUTER force measuring devices or test stand systems
  • To fix the clamp on a force gauge, there is a M6 thread on the upper side of the clamp
  • For tension and compression testing up to 500 N
  • Overload protection: 150 % of [Max]
  • Scope of supply: 1 clamp with 2 jaws with pyramid-shaped grip
Vezi mai mult

Latimea carcasei: 51 mm

Adancimea carcasei: 41 mm

Inaltimea carcasei: 15 mm

Greutate bruta: 0,10 kg

Dimensiuni ambalaj: 51×41×15 mm

Accesorii

Adaptor AFM 01

107,10 RON *

Adaptor AFM 02

107,10 RON *

Adaptor AFM 03

107,10 RON *

Adaptor AFM 13

107,10 RON *
